Bolted Bonnet Gate Valve
What is bolted bonnet in the gate valve?
The bolted-bonnet joint of the gate valve is the most favoured, and it is used on the majority of gate valves in industrial use today. Unlike threaded and union bonnet valves, the bolted-bonnet connection requires a gasket to seal the joint between the body and bonnet.
The Major Components Of Bolted Bonnet Gate Valve.
Body: It confirms that the bolted bonnet gate valve maintains resistance to flow and optimum performance and strength.
The body on the bonnet was constructed using the same standard of the bonnet that assemblies Yoke and Bonnet.
Gate valves of a bigger size make use of multi-piece bonnet designs.
Gland: it compresses the packing to form a stem seal above the backseat between the stem and bonnet.
Stem: it has an integral back seat shoulder that links to the integral backseat of the bonnet.
Wedge: it ensures that the bolted bonnet gate valve can fast shut off and cycle.
Hand-wheel: it cycles the nuts of the bonnet gate valve.
Bonnet: It protects the internal parts of a bolted bonnet gate valve. It can either be run or screwed to the valve body.
What Is The Difference Between Bolted Bonnet Gate Valve Vs Welded Bonnet Gate Valve?
Some of the differences between bolted bonnet gate valve and Welded Bonnet gate valve include:
Welded bonnet gate valves tend to be smaller than bolted bonnet gate valves.
Welded bonnet needs to be cut off from the system of piping to be reset.
In steam piping, Bolted bonnet gate valves are used mainly in steam piping systems. Welded bonnet gate valves, on the other hand, are used mainly in toxic or lethal services.
What Are The Applications Of Bolted Bonnet Gate Valve?
Some of the applications of bolted bonnet gate valve:
Transmission pipelines
Offshore platforms
Measuring stations
Onshore terminals
Compression, pumping, and re-injection units.
Surge-relief skids
